Lightweight Magnesium Outdoor LED Display with 7680Hz refresh rate and hoisting support for rental and advertising
Product Details:
| Place of Origin: | China |
| Brand Name: | CHARMING |
| Certification: | CE,ROHS,LVD,EMC,CB,BIS,UL |
| Model Number: | P5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case, Wooden Case, Flight Case |
| Delivery Time: | 30 working days after payment |
| Payment Terms: | T/T,L/C,Western Union,Paypal,Cash |
| Supply Ability: | 500 PCS per week |
|
Detail Information |
|||
| Cabinet Materia: | Magnesium Alloy | Pixel Density: | 40000Dot/㎡ |
|---|---|---|---|
| Screen Resolution: | 192*192 | Power Quantit: | 3Pcs |
| Working Temperature: | -20~+60℃ | Life Span: | ≥50000 Hours |
| Highlight: | lightweight magnesium outdoor LED display,outdoor LED video wall with hoisting support,LED display with 7680Hz refresh rate |
||
Product Description
| Pixel Pitch | 5.0mm |
| Brightness |
≥5500CD/㎡
|
|
Refreshrate
|
7680Hz
|
| Cabinet Weight | 26.6 kg |
|
Protection level
|
IP65
|
| Max. Power | 900W |
|
Miaintenance Method
|
rear maintenance
|
|
Best Viewing Distance
|
≥5M
|
-
5mm pixel pitch with 40,000 dots/m² density provides excellent visibility at distances over 5 meters, perfect for large-scale outdoor advertising and live events.
-
Magnesium alloy die-cast frame weighs only 26.6kg per cabinet, significantly reducing structural support requirements and transportation costs.
-
128mm ultra-thin profile enables sleek, low-profile installation while maintaining robust structural integrity for demanding outdoor conditions.
-
Integrated fast lockers on top and left sides enable rapid cabinet assembly, while built-in hanging bars support both ground and suspended installations.
-
Comprehensive IP65 protection with waterproof rubber seals and keyhole covers ensures dependable performance in rain, snow, and extreme temperatures from -20°C to +60°C.
