CH-H Series Curved Indoor LED Video Wall with Circular Splicing for Immersive Stage Design
Product Details:
| Place of Origin: | China |
| Brand Name: | CHARMING |
| Certification: | CE,ROHS,LVD,EMC,CB,BIS,UL |
| Model Number: | P2.604 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case, Wooden Case, Flight Case |
| Delivery Time: | 30 working days after payment |
| Payment Terms: | T/T,L/C,Western Union,Paypal,Cash |
| Supply Ability: | 500 PCS per week |
|
Detail Information |
|||
| Pixel Density: | 147456 | Grey Level: | 14-16 Bit |
|---|---|---|---|
| View Angle: | 140° | Dimension: | 500x500x84mm |
| Working Temperature: | -20~40℃ | Cablnet Material: | Die-cast Aluminum Alloy |
| Highlight: | curved indoor LED video wall,circular splicing LED display,rental LED display for stage |
||
Product Description
CH-H Series Curved Indoor LED Video Wall with Circular Splicing for Immersive Stage Design
CH-H Series Curved Indoor LED Video Wall with Circular Splicing for Immersive Stage Design
| Pixel Pitch | 2.604mm |
| Cabinet Weight | 7.9 kg |
| View angle | 140° |
| Refresh rate | 7680Hz |
| Max.Power | 100W |
| Brightness | 600-800CD/㎡ |
Product Features
-
Maximum outer curvature 10° with 36 cabinets forming a complete circle.
-
Maximum inner curvature 15° with 24 cabinets forming a full circle of 5.8m diameter.
-
45° beveled cabinet design with accessory lock replacement for varied installation needs.
-
Dedicated curved lock for arc splicing and straight edge lock for flat splicing.
-
Operating temperature -20~40℃ with 10%~65%RH humidity and ≥50000 hours lifespan.
