Lightweight P7.8 Outdoor Glass Wall LED Video Screen For Outdoor Advertising
Product Details:
Place of Origin: | China |
Brand Name: | Charming |
Certification: | CE, ROHS, LVD, EMC, CB, BIS, UL |
Model Number: | P3.91 |
Payment & Shipping Terms:
Minimum Order Quantity: | 2 PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Carton Case, Wooden Case, Flight Case |
Delivery Time: | 10 Working Days after Payment |
Payment Terms: | L/C, T/T, Western Union, Paypal, Cash |
Supply Ability: | 1000 PCS per week |
Detail Information |
|||
Dimension(MM): | 500 X 500x 88.5MM / 500x1000x88.5 | Max.Power(W): | 200W / 400W |
---|---|---|---|
Cabinet Weight(KG): | 6.2KG / 11.2KG | Brightness(CD/㎡): | ≥ 5000 CD/㎡ |
LED Standard: | SMD 1921 | Viewing Angle: | 140 ° |
Protection Level: | IP 65 | Refresh Rate(Hz): | 1920Hz / 3840Hz |
Pixel Pitch(MM): | 3.91 - 7.8125 MM | Life Span: | 50000H |
High Light: | Outdoor Glass Wall LED Video Screen,P7.8 LED Video Screen |
Product Description
Lightweight and Durable P7.8 Outdoor Glass Wall LED Video Screen for Outdoor Advertising
Product feature:
1):Cabinet material are made by megnisum alloy;
2):thin design; light weight:only6.2KG;
3):High brightness: over 5000CD/㎡;
4):IP65 Waterproof and wind resistance;
product introduce:
1)Module magnetic suction front maintenance.New lock buckle forgreater safety;
2)The cabinet is made of aviation magnesium alloy material, which has strong rigidity Lightweight and has excellent hysteresis and shock absorption performance.
3)Adopting high brightness waterproof LED light module,with a brightness of up to 5000CD/㎡
4)Ensure image quality while alsoconsideringwaterproofing performance.Can meet outdoorrental needs.The silicone waterproof ring on thedoor panel provides better waterproofeffect,Longer service life.
Product parameter
Dimension(MM) | 500*500*85mm/500*1000*85mm |
Max.Power(w) | 200W/400W |
Cabinet Weight(KG) |
6.2KG/11.2KG |
Brightness(CD/m²) | ≥5000 CD/㎡ |
LED Standard | SMD1921 |
Viewing Angle | 140° |
Protection Level | IP65 |
Refresh Rate(Hz) | 1920Hz/3840Hz |
Pixel Pitch(MM) | 3.91-7.8125MM |
Scan Mode | 1/8Scan |
Pixel Density(Dot/㎡) | 32768 Dot/m² |
Cabinet Material | Magnesium Alloy |
Maintenance Method | Back Maintenance |
Grey Level | 16 Bit |
Working Temperature | -20~60℃ |
Working Humidity | 10%-90%RH |
Life Span | ≥50000 Hours |
Working voltage | AC 110W/220V,50V60HZ |
Charming Co., ltd has always been committed to technical innovation and service of global entertainmet lighting & LED.
We specializes in the production of LED display products such as indoor and outdoor LED video walls, transparent LED video walls, and LED strip lights. They also offer rental services for LED displays and have a focus on high-quality products with waterproof and anti-collision.
It has obtained nearly 100 patents and obtained ISO9001, CCC, CE, CB, ROHS, SASO and other certifications.
In 2003, the world's first led display was brought into the field of the entertainmnet applications, and contiunes to lead the trend of LED's in this field. It has developed into the first brand of customer satisfaction in China's entertainment lighting Led.
Adhering to the corporate philosophy of " Charming Achieve Beauty ", we have an international standard full-automatic led display production line with a factory area of more than 10,000 sqm. We have provided quality products and services to customers in more than 150 countries and regions for 20 years.
1. How much is the freight ?
The shipping cost is determined by the size of the screen, and the project information is informed by the inquiry.
2. What is the warranty ?
1 years Warranty.
3. What is Price per square meter of screen ?
Welcome to send us inquiry. Our professional sales engineers will provide suitable solutions.
4.What is your payment term?
alibaba,T/T, Paypal, or other is acceptable.This can be negotiable.
5. Can I have customization service ?
Of course. All the products can be customized. we have a professional product development team.welcome to inquiry.
6.How to choose a best pixel pitch?
Answer: Choose the suitable pixel model according to the closest viewing distance, the smaller the value, the clearer!
7. Is it OK to print my logo on the products?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
8: How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new module with new order for small quantity.
For defective batch products, we will repair them and resend them to you or we can discuss the solution
including re-call according to real situation.
