High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen

Product Details:

Place of Origin: China
Brand Name: Charming
Certification: CE, ROHS, LVD, EMC, CB, BIS, UL
Model Number: P3.91

Payment & Shipping Terms:

Minimum Order Quantity: 2 PCS
Price: Negotiable
Packaging Details: Carton Case, Wooden Case, Flight Case
Delivery Time: 10 Working Days after Payment
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 1000 PCS per week
Get Best Price Contact Now

Detail Information

Dimension(MM): 500x*500mm/500*1000mm MaxPower(W): 100w /200 W/400w
Cabinet Weight(KG): 8 /14.5 Kg Brightness(CD/m²): 600 /4500 CD/m²
LED Standard: SMD1921 / SMD2020 Pixel Density(Dot/㎡): 65536 Dot/㎡
Protection Level: IP42 / IP65 Refresh Rate(Hz): 1920Hz / 3840Hz
Scan Mode: 1/16 Working Humidity: 10%-90% RH
Working Tempreture: -20-60 ℃

Product Description

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen




product details





1)Seamless splicing : give you a better visual experience.

2)High brightness and no damage to gray scale, achieving the debugging technology for nice image.

3)Reliable - high strength hardness, good heat dissipation;

4)Cabinet light, quick installation, removal and transportation, suitable for large-scale fixed installation and rental application site.



High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 0



High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 1


advantages:

1)strong rigid, not easy to deform,more accurate splicing.

2)no deformation,more accurate splicing,ergonomic structural design,easyinstallation by one person.​

3)Supporting the truss connectingrental cabinet quickly,as well as the hoisting and fixedinstallation of the truss.

4)Effectively protecting the led lampof the corner led modules fromcolliding and falling off duringtransportation or repeateddisassembly when for rental.

5)Seamless splicing : give you a better visual experience.

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 2High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 3High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 4

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 5






Product parameters



Type Number
RK391-H
Dimension(MM)
500x 500x 86MM/500x 1000x 86MM
Max.Power(W)
100W/200W/400W
Cabinet Weight(KG)
8KG/14.5KG
Brightness(CD/㎡)
600/4500
LED Standard SMD1921/SMD2020
Viewing Angle
120°/140°
Protection Level
IP42/IP65
Pixel Pitch(MM)
3.91MM
Scan Mode
1/16 Scan
Module Max.Power(W) 200W
Pixel Density(Dot/m²)
65536 Dot/㎡
Cabinet Material
Aluminum Alloy
Maintenance Method
Back Maintenance
Grey level 16bit
Working temperature -20~60C℃
Working humidity 10%-90%RH
Life span ≥50000 Hours
Working voltage AC 110V/220V,50/60HZ

Company Profile


High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 6



Charming Co., ltd has always been committed to technical innovation and service of global entertainmet lighting & LED.

In 2003, the world's first led screen was brought into the field of the entertainmnet applications, and contiunes to lead the trend of LED's in this field. It has developed into the first brand of customer satisfaction in China's entertainment lighting LED.

It has obtained nearly 100 patents and obtained ISO9001, CCC,CE, CB,, ROHS, SASO and other certifications.

Adhering to the corporate philosophy of " Charming Achieve Beauty ", we have an international standard full-automatic led display production line with a factory area of more than 10,000 SQM. We have provided quality products and services to customers in more than 150 countries and regions for 20 years.

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 7


High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 8
Packaging:

High Performance Led Video Wall Screen P3.91 Indoor Outdoor Led Display Screen 9
What we offer to customer?

Q1.How to choose a best pixel pitch?



Answer: Choose the suitable pixel model according to the closest viewing distance, the smaller the value, the clearer!


Q2. How to install and debug?


Answer: We will make drawings and build the fixed structure and installation according to the drawings. Engineers will video remotely debugging assistance and training you how to use!


Q3.What's the warranty?


Answer: 1 years warranty! We will prepare enough spare parts for you, if there are broken parts, can be replaced in time without affecting the use of!
