IP65 Waterproof Transparent LED Wall , Anti Collision Transparent Video Glass Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | Charming |
| Certification: | CE, ROHS, LVD, EMC, CB, BIS, UL |
| Model Number: | P3.91 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case, Wooden Case, Flight Case |
| Delivery Time: | 10 Working Days after Payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, Cash |
| Supply Ability: | 1000 PCS per week |
|
Detail Information |
|||
| Product Name: | P3.91 Outdoor Transparent Led Display | Refresh Rate: | 1920hz-3840hz |
|---|---|---|---|
| Pixel Pitch: | 3.91mm-7.8mm | Brightness: | ≥5500CD/M² |
| IP Rate: | IP65 | Resolution: | 256x64 |
| Size: | 1000x500mm | Module Size: | 250x250mm |
| High Light: | IP65 Transparent LED Wall,Waterproof Transparent LED Wall,Anti Collision Transparent Video Glass Screen |
||
Product Description
Outdoor 3.91 Transparent Led Video Wall 4K Advertising Led Wall
Product Details
1. High Transparency
It used the display screen combined with the louver structure principle .The spaces are arranged through the lamp bars can achieve light transmittance over 60%-65%.Realized light and air permeability, without affacting lighting and line of sight .
2. HD Full Color Display
256*64 display resolution , each pixel is composed of 1R1G1B , high-definition full color display , bringing a better visual experience .
3. Waterproof Performance
The high-brightness waterproof LED lamp module is used for outdoor use while ensuring the quality of the image while providing waterproof performance.
Cabinet Detail
Die-casting Aluminum cabinet. Strong regidity, no deformation, more accurate splicing , ergonomic structural design easy installation by one person.
Product Parameters
|
Type Number |
H391S |
|---|---|
|
Dimension(MM) |
1000*500*73MM |
|
Max Power(W) |
230W |
|
Cabinet Weight(KG) |
7KG |
|
Refresh Rate(Hz) |
3840Hz / 1920Hz |
|
Pixel Pitch(MM) |
3.91MM |
|
Led Standard |
SMD2020 |
|
Pixel Density(Dot/M²) |
32768 Dot/M² |
|
Brightness(CD/M²) |
≥5500CD/M² |
|
Viewing Angle |
140° |
|
IP Rate |
IP65 |
|
Cabinet Material |
Aluminum Alloy |
|
Maintenance |
Back Service |
|
Grey Level |
16 bit |
|
Working Temperature |
20~60℃ |
|
Working Humidity |
10%~90%RH |
|
Life Span |
≥50000 Hours |
|
Working Voltage |
AC110V/220V, 50/60Hz |
Installation Details
1.Splicing the box into the required size and shape, aligning the hole with the quick lock to fix the box.
2.Distinguish the power cable and the signal cable, and insert the power cable and the signal cable into the corresponding places of the box.
3.Connect the main signal cable and the main power cable to the computer and the controller, and use it successfully after debugging the screen.
Screen Usage
Outdoor rental led screen is suitable for corporate events, exhibitions, theaters, trade show and wedding function and birthday party and so on. Light and thin appearance can be faster to install, easy to maintain and meet high-end needs. Advanced materials can increase the service life.High refresh 3840HZ can show smooth video effect. The quality is clear and the colors are bright and distinct.
Package Details
We have carton case, wooden case, flight case to choose from.Different products will be configured with different packaging, in order to better protect the screen.
Production process
Our brand has a history of 19 years, a complete production system and production line. With its own factory, it can realize mechanical automation production and reduce manual errors. Truly achieve high quality and low price, and provide customers with the best products at the lowest price.
Shipping Details
Provide multiple modes of transportation such as sea, land, air and so on. We have a long-term cooperative international logistics company, and our products can be sold all over the world. So far our products have been sold to more than 150 countries and regions around the world.
