High-Refresh-Rate Indoor LED Soft Module Video Wall for Light Advertising Campaigns and Event Organization
Product Details:
| Place of Origin: | China |
| Brand Name: | charming |
| Certification: | CE,ROHS,LVD,EMC,CB,BIS,UL |
| Model Number: | P1.86/P2/P2.5/P3/P3.076/P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton Case,Wooden Case,Flight Case |
| Delivery Time: | 7 Working Days after Payment |
| Payment Terms: | Western Union, L/C, T/T,Paypal,Cash |
| Supply Ability: | 10000 PCS per week |
|
Detail Information |
|||
| Dimension(MM): | 256×128×7.5MM | Protection Level: | IP40 |
|---|---|---|---|
| Brightness（CD/ ）: | 1000 | Life Span: | 1000000 Hours |
| Working Temperature: | -20～50℃ | Pixel Pitch(MM): | 2MM/2.5MM/3MM/1.86MM |
| Working Voltage: | AC 220V/（110V）±15% | Working Humidity: | 10%-65%RH |
Product Description
Specification
| Type Number | P1.86 | P2 | P2.5 | P3 | P3.076 | P4 |
| Dim ension(MM) |
320*160*7.5MM
|
320*160*7.5MM | 320*160*7.5MM |
240*120*7.5MM
|
320*160*7.5MM
|
256*128*7.5MM |
| Module Maximum power(w) | 23 | 25 | 25 | 13 | 18 | 6 |
| Module weight(g) | 270 | 270 | 270 | 170 | 250 | 255 |
| LED Standard |
SMD1515
|
SMD1515 |
SMD 2020
|
SMD 2020
|
SMD2020 | SMD2020 |
| Scan Mode |
1/43Scan
|
1/40Scan
|
1/32Scan
|
1/20Scan
|
1/26Scan | 1/32Scan |
| Pixel Density(Dot/m²) |
288906 Dot/m²
|
250000 Dot/m²
|
160000Dot/m²
|
111111Dot/m²
|
105625 Dot/m² | 62500Dot/m² |
|
Refresh Rate(Hz)
|
7680Hz | 7680Hz | 7680Hz | 3840Hz/1920Hz | 1920Hz/38400Hz | 1920Hz/3840Hz |
|
Brightness(CD/ m²)
|
＞800 |
>700 | >800 | >800 | >700 | >400 |
| Pixel Pitch(MM) | 1.86 | 2 | 2.5 | 3 | 3.076 | 4 |
|
Protection Level
|
IP40
|
IP40 | IP40 | IP40 | IP40 | IP40 |
|
Grey Level
|
14-16 bit
|
14-16bit | 14-16bit | 14-16bit | 14-16bit | 14-16bit |
|
Working Temperature
|
-20～50℃
|
-20～50℃
|
-20~50°C | -20~50°C | -20~50°C | -20~50°C |
|
Working Humidity
|
10%～65%RH
|
10%～65%RH
|
10％~65％RH | 10％~65％RH | 10％~65％RH | 10％~65％RH |
|
Life Span
|
≥30000 Hours
|
≥30000 Hours |
≥30000 Hours | ≥30000 Hours | ≥30000 Hours | ≥30000 Hours |
|
Working Voltage
|
AC 220V/(110V)±15%
|
AC 220V/(110V)±15% |
AC 220V/(110V)±15% | AC 220V/(110V)±15% | AC 220V/(110V)±15% | AC 220V/(110V)±15% |
Company introduction
1. How to obtain the price?
- We generally provide a quote within 24 hours of receiving your inquiry.
- In case of urgency, please reach out to us via email or other communication channels, and we'll promptly offer you a price quote.
2. Can I purchase samples before placing an order?
- Absolutely. Please don't hesitate to get in touch with us.
3. What is the delivery time?
- The lead time varies based on the order quantity and the season when the order is placed.
- For small - scale orders, we can usually arrange shipping within 7 - 15 days, while for large - scale orders, it takes around 30 days.
4. What are the payment terms?
- We accept T/T, Paypal, Ali, and other methods. The payment terms are open to negotiation.
Warranty
Our commitment to quality is underscored by a comprehensive two-year warranty that covers all displays, modules, and parts. Should any item prove defective, we’ll replace or repair it at no cost. Beyond the warranty period, we offer lifetime maintenance services, charging solely for raw materials. To ensure you can maximize the performance of our LED screens, we provide free in-factory training on operation and maintenance. You’ll also receive essential resources, including an operation manual, software, test report, and CAD assembly drawings. On top of that, our experts are always on standby to offer professional advice.
